LOW PROFILE TELESCOPIC PORTABLE RADIAL CONVEYOR

THOR GLOBAL’S PATENTED LOW PROFILE DESIGN HAS THE LOWEST FEED HEIGHT IN THE INDUSTRY WHILE MAINTAINING A LARGE TRUSS DEPTH FOR STRENGTH AND STABILITY. THESE CONVEYORS ARE HIGHWAY PORTABLE. ALL BENEFITS OF A THORSTACKER™ CONVEYOR ARE AVAILABLE IN THIS LOW PROFILE PACKAGE.

ELIMINATE SPILLAGE

The patent-pending low profile assembly design enables the feed angle to remain constant, thus eliminating spillage.

MAXIMUM VERSATILITY

Lowest feed height in the industry provides maximum versatility.

CUT COSTS

Eliminate the need for additional conveying equipment.

USED IN THESE INDUSTRIES: AGGREGATE, AGRICULTURE & RECYCLING

JRA_0237
press to zoom
JRA_0247
press to zoom
JRA_0013
press to zoom
JRA_0377
press to zoom
JRA_0334
press to zoom
JRA_0114
press to zoom
JRA_0222
press to zoom
JRA_0002
press to zoom
1/1

MODEL

LPT130x36-0500/0800

LPT150x36-0500/0800/1000

LPT150x42-1200/1500

BELT WIDTH

36in

36in

42in

CAPACITY

500/800 stph

500/800/1000 stph

1200/1500 stph

LENGTH

130ft

150ft

150ft

STANDARD FEATURES
OPTIONAL FEATURES
SPECIALTY FEATURES
Gravel

STANDARD FEATURES

Belt Scrapers (Twin Edge) & Tensioning system.jpg

Belt Scrapers (Twin-Edge) & Tensioning System: Patented

Situated at the discharge end on both conveyors, Thor’s exclusive twin-edge belt scrapers are designed for a cleaner return and longer belt life. All scrapers are manufactured using a tough ¾” thick, 10” wide urethane blade combined with an extension spring. The blade is reversible for double lifespan. The PATENTED belt scraper tensioning system provides maximum control and better usage of the blade.

Belt Splice - Vulcanized.jpg

Belt Splice:

HOT Vulcanized

All belt splices are hot vulcanized in house to ensure greater belt life for all of our end users. Vulcanizing also prolongs the life of the belt scraper. Thor Global uses premium quality and high tensile strength belting.

Cable Slack & Tension Detection.jpg

Cable Slack & Tension Detection

The cable slack and tension detection system utilizes the PLC to constantly monitor cable tension and alert the operator when the cable needs to be adjusted. This failsafe system is easily accessible when adjustments are required. All machines use standard 9/16” or greater cables to add strength and reliability.

Contactors - IEC.jpg

Contactors: IEC

Thor Global is very aware that bulk material handling environments can be extremely harsh on electrical components. This is why the conveyor uses over sized IEC contactors for all applications to provide a more robust system
Electrical Cable Harness Pulley.jpg

Electrical Cable Harness Pulley: UHMW

Custom made UHMW pulleys, which are attached to the electrical cable harness that supplies the inner truss, are guaranteed not to seize up.

Emergency Braking System.jpg

DUAL Emergency Braking System

In the unlikely event of winch cable breakage, the braking system is immediately engaged, preventing the inner truss assembly from traveling backwards. The emergency braking system will prevent excessive damage from occurring and more importantly eliminates the risk of injury to any individual.

Gear Reducers - CLASS 2.jpg

Gear Reducers: CLASS 2

Dodge, always CLASS 2 with no need to upgrade from CLASS 1.

Hydraulic Cylinders - Single Stage 2.jpg

Hydraulic Cylinders: Single Stage

Single-Stage hydraulic cylinders provide a simple, more reliable solution than complex multi-stage hydraulic cylinders.

Idlers - CEMA C.jpg

Idlers: CEMA C

Nordstrong CEMA C idlers are standard on all machines. They are intended to last twice as long as CEMA B. Thor uses nothing less than the best!

In-line Swing Axle.jpg

In-line Swing Axle

The exclusive inline swing axle design is the only system that enables the machine to radial in a smooth motion without straining or scuffing the tires. The wheels remain in a perfect arc because they are in-line or side-by-side at all times. The axle design is 27ft in radial mode providing the most stable structure on the market.
Inductive Proximity Sensors.jpg

Inductive Proximity Sensors

Inductive proximity sensors utilize the PLC to accurately track the radial drive and telescopic position of the conveyor, providing increased flexibility in determining radial travel and extension/retraction parameters. The radial drive sensor is located on the non-drive side of the wheel to guarantee accuracy.


Automation Technology

Automation Technology uses various sensors connected to a PLC in order to perform the following automated functions: Pile Detection & Material Flow (Standard) Radial Drive & Telescopic Position (Standard) Cable Slack & Tension Detection (Standard) Belt Tracking (Optional) The most unique function of Thor’s Automation Technology is the ability to change parameters “on-the-fly” during automatic mode of any program.

LES - Patented.jpg

LES: Patented

The patented LES (Load Equalizing System) was engineered to evenly distribute the constantly changing load of the inner truss as it extends and retracts. When extending and retracting a telescopic, the forces applied to the inner structure can be very high. The system uses a unique 4 / 8 roller design to effectively distribute this load over the entire inner structure. The LES is located under the inner conveyor to avoid material build up. The combination of the upper and lower LES keeps loads even on all rollers for worry-free operation.

Limit Switches - NEMA 4.jpg

Limit Switches: NEMA 4

NEMA 4 rated back-up safety switches are located in various positions across the stacker. Weatherproof seals ensure that the switches operate reliably under harsh conditions, thereby eliminating potential downtime.

PLC - Micrologix 1400.jpg

PLC: MICROLOGIX 1400

The automation control system uses the legendary bulletproof Allen-Bradley MicroLogix 1400 Control System with an ethernet port for web server compatibility and a built in LCD for I/O status control. The system is powerful, reliable and flexible.

Program - Windows Auto Mode.jpg

Program: Windrow Auto Mode

Thor Global’s basic programming was originally designed to minimize segregation by stockpiling material in concentric rows called windrows. The operator has the ability to set specific parameters based on a radial degree limit and extension retraction limit.

Push Button Control.jpg

Push Button Control

As a preventative measure, Thor Global has applied basic push button technology in addition to the standard touch screen system to provide a failsafe back-up system for increased comfort and reliability.

Safety Guard 1.jpg

Safety Guarding

PVC coated wire mesh guarding surrounding the main conveyor and safety guards at all pinch points provide ultimate protection for all operators and personnel within close range of the conveyor.

Side Guide Rollers - UHMW.jpg

Side Guide Rollers: UHMW

Thor Global’s more forgiving UHMW guidance system does not employ metal on metal contact and covers the entire height of the inner chord prolonging the lifespan of the inner telescopic.


Steel: 60,000 psi

Thor Global uses 60,000 psi yield strength steel versus the industry norm of 45,000 psi yield strength for all HSS (Hollow Structural Section) tubing. This FINER grain steel provides additional strength without additional weight.


Stone Box Skirting (Floating): UHMW

Located between the stone box and the conveyor belt, the UHMW skirting is designed to “float” on the belt via slotted holes, maintaining a constant point of contact, thereby minimizing spillage and wear due to friction.

Transport Landing LEgs - regular.jpg

Transport Landing Legs: Regular

Landing legs are required when loaders are not available to lift the conveyor off the truck. These Landing Legs allow you to unhook the conveyor from the transport truck without the need for additional equipment. Additional cranks allows you to lift and lower the legs  (not the machine).

Tail Pulley Kick Bar.jpg

Tail Pulley Kicker Bar

A kicker bar is attached to the tail pillow block bearings of the inner and outer conveyors to keep material off the pulley, which prevents tracking and belt damage.

Tail Undercarriage Hinge point.jpg

Tail Undercarriage Hinge Point

This original Thor design removes all lateral stress from the radial arms, as the unit is being raised or lowered. The extended hinge point enables the onveyor to raise and lower “on-the-fly” (without stopping the machine), which effectively helps to provide segregation free material..

Touch Screen Control.jpg

Touch Screen Control: schneider harmony hmi 10"

The touch-screen control provides a simple to use and fully automated program for setting parameters and pile configurations. All controls are on the same screen. TFT Technology ensures a bright screen that can be viewed from all angles with minimal glare. These screens come with standard replacable overlays, to ensure a clear view.

THOR

Quick-Release System

This system allows the operator to easily engage or disengage the chain drive system for travel or working positions within less than 3 minutes, minimizing set-up and tear down time. This chain does not need to be taken apart when putting it on or taking it off the wheel drive sprocket.


Training: Onsite

A factory trained, Thor authorized representative will be on site to ensure that you and your operators know all there is to know about how the conveyor operates.

Transport Auxilary Axle.jpg

Transport Auxiliary Axle

The axle is a specially designed outrigger style framework with 8 radial tires mounted onto standard 10-stud hub and transportation/truck spindles, bearings. Wheels are equipped with air-actuated brakes for transport. An auxiliary axle is included where required by law for road restrictions.

Transport Flip Box.jpg

Transport Flip Box

Kingpin, counterweight and side plate assemblies are designed to allow ample turning clearance for most 5th wheel tractors, as well as easier and quicker hook-up from operating to transport positions.

Transport Mobility.jpg

Transport Mobility

All portable conveyors (including the T190 series) are designed to stay within most transportation regulations. The machine can be folded up and ready for transport in under 12 minutes.

Ultrasonic Sensors.jpg

Ultrasonic Sensors

Ultrasonic sensors utilize the PLC to automatically maintain a pre-determined drop distance from the head pulley to the stockpile as well as stopping all radial movement when no material is detected on the conveyor belt. These sensors never come in contact with the material and are maintenance free.

Variable Frequency Drive.jpg

Variable Frequency Drive

Variable frequency drive provides smooth acceleration and deceleration of the radial movement, eliminating jerky or jarring starts and stops. The VFD (Variable Frequency Drive) also allows the operator to adjust the radial travel speed.

OPTIONAL FEATURES

Anchor Pad.jpg

Anchor Pad: Portable

Thor has developed a strong steel fabricated anchor pad that is very compact and portable. The anchor pad conveniently fits into the receiving hopper for transport.

THOR

RECEIVING Chute: Custom

A customized box shaped design has tapered sides with a wider feed opening. Other custom designs are available upon request.

Colour - custom.jpg

Colour: Custom

We understand the importance of corporate image, so we at Thor Global will always try to meet the specific requests of our customers as best as we can.

Dual drive.jpg

Dual Drive

An optional second radial drive allows the conveyor to maintain traction in the most demanding conditions.

Galvanizing - hot dip.jpg

Galvanizing: Hot-Dip

Realizing that some customers have to work in harsh environments with corrosive materials, Thor is the first and only manufacturer to provide a unit that can withstand your tough environment. Machines are fully Hot-Dip galvanized before assembly. Hot-Dip Galvanizing relieves the internal stresses of welded components, providing a fully stress relieved structure. Zinc has a very high relative corrosion resistance.

Program package - zero segregation and max pile.jpg

Program Package: Zero Segregation & Max Pile Auto Mode

Zero segregation programming is recommended when minimizing segregation is of the utmost importance. The primary function of zero segregation programming is a stepping function, which prevents material segregation along the outside of the pile in addition to the inside of the pile. The most unique function of Thor’s zero segregation program, is the ability to control the degree of step, which enables you to control the exact size of the pile. Max Pile programming is recommended when segregation is not of any importance. The conveyor minimizes all movements in this auto mode.

Hydraulic Push Down Axle.jpg

Push Down Axle: Patent-Pending

Hydraulically operated “push down” axles lift the machine to allow quick and easy movement of the machine without the need to move the main axle from radial to transport mode.

Tow Hitch.jpg

Tow Hitch

The tow hitch provides quick and easy movement within the worksite.

Transport Landing Legs - Hydraulic.jpg

Transport Landing Legs: Hydraulic complete with 12v power pack

Hydraulic landing legs provide the same benefits as regular landing legs with the added flexibility of lowering the conveyor into operating mode after it is unhooked from the transport truck. Hydraulic landing legs may also be used to raise the conveyor onto a transport truck.

THOR

WireD Remote Touch Screen: Dual

Dual wire remote control involves keeping the touch screen panel on the conveyor and adding a second panel up to 330ft away from the conveyor without a repeater. A selector switch is applied to control which control station is active. Dual wire remote control provides increased versatility.

Wireless remote control.jpg

Wireless Remote Control

This system allows wireless remote control operation of the conveyor for movements such as telescoping in and out, or luffing and slewing. Wireless remote control provides increased visibility and flexibility. Wireless remote control is ideal for ship loading applications where visibility from the main control panel is limited.

SPECIALTY FEATURES

Belt Alignment Sensor

A belt alignment sensor may be applied in connection with the PLC to monitor the belt alignment and alert the operator when an adjustment is required to further extend belt longevity. Also known as belt tracking.

THOR

Mobile Track Unit

The mobile track unit is a versatile solution for moving a conveyor quickly and safely on location. The unit acts as a fully functional anchor pad, thus eliminating the need for an external anchor pad. It can be fitted with an external electrical power supply hookup or an independent diesel genset engine. Optional wireless remote operation capabilities are available upon request. All units are wired directly to a push button control box, which is configured with two speed settings (85 fpm and 170 fpm). All units are also equipped with an emergency stop push button. Thor mobile track units can also be used with other types of equipment using a 5th wheel hookup.

THOR

Telescoping Spout

A telescoping spout has been designed for applications that require specialized dust control. This unit can be attached to select models. The spout is connected to the PLC for automated control with an extension of up to 16ft. The spout can be retracted to a minimum of 4ft. Telescopic spouts are ideal for ship loading applications.

THOR

Belt Covers: Patented

Thor Global’s patented belt covers can be easily installed into any existing conveyor system. Ultra lightweight galvanized steel structural tubing and single bolt connections make these conveyor covers easy to handle, remove and assemble. Individual spring tensioning systems keep the covers secure and accessible for maintenance and repair. Lightweight UV resistant polyurethane material dramatically reduces wind load by 80%. Provides excellent dust control.

Spray Bar

Inner and outer telescopic truss configurations are available upon request.
